Pressure rating:150LB~900LB

Size: 6“~44”

Design Standards:

ASME B16.34

ASME B16.25

API 6FA

API 609

BS 6364

ISO 28921-1

ISO 15848-1 Class B

Temperature:-196℃~ +150℃

Technical Features:•

•Enhanced spring and low temperature resistant soft materials in sealing ring

• Online maintenance available

• Anti-blowout stem

• Triple offset design

• Extended Bonnet

• Fire Safe Design

• Unique Sealing System

Main materials:

Casting Material:ASTM A351CF8,ASTM A351CF8M,ASTM A351CF3,ASTM A351CF3M,

Forging Material: ASTM A182 F304,ASTM A182F316,ASTM A182F304L,ASTM A182F316L

Stem：17-4PH (ASTM A564 Type 630)

Bolt/Nut: ASTM A320 B8M CL.2/ A194 8M

Leakage Standard

BS 6364 100mm3/s X DN

MSS SP-134 75 cc/min/NPS

ISO28921-1 50 mm3/s X DN
